Horizontal ribbon mixer machine has a single blending shaft with double helical ribbons. This machine is widely used in mixing dry powder, granules, particles, pellets, and low viscous paste materials, with options for spraying liquid or oil during the mixing process.
| Model | Total volume | Loading volume | Capacity | Mixing time | Motor/speed | Dimension(L×W×H) | Weight |
|---|---|---|---|---|---|---|---|
| RM-100 | 100L | 50L | 50kg | 0~999Min | 2.2kw/58rpm | 1190×740×790mm | 380kg |
| RM-200 | 200L | 100L | 100kg | 0~999Min | 3kw/53rpm | 2030×630×980mm | 450kg |
| RM-300 | 300L | 180L | 200kg | 0~999Min | 4kw/41rpm | 2280×680×880mm | 550kg |
| RM-500 | 500L | 300L | 300kg | 0~999Min | 5.5kw/41rpm | 2670×780×1240mm | 900kg |
| RM-1M³ | 1M³ | 0.6M³ | 600kg | 0~999Min | 11kw/33rpm | 3140×980×1400mm | 1600kg |
| RM-2M³ | 2M³ | 1.2M³ | 1200kg | 0~999Min | 15kw/33rpm | 3860×1200×1650mm | 2700kg |
| RM-5M³ | 5M³ | 3M³ | 3000kg | 0~999Min | 30kw/27rpm | 5280×1550×2100mm | 5100kg |
| RM-10M³ | 10M³ | 6M³ | 6000kg | 0~999Min | 45kw/22rpm | 5610×1750×2650mm | 7800kg |
The equipment is suitable for various industrial applications including Food, Pharmaceutical, Chemical, Energy, and Mineral processing.
